Self-regulating Heating Cable Series 2800

Performance Ratings
Output wattage:
3, 5, 6 w/ft @ 40¡ãF

Supply voltages:
2803, 2805: 110 - 120 Vac
2806: 120 or 208V - 277 Vac

Continuous maintenance temperature:
150¡ãF (65¡ãC) max

Intermittent exposure temperature:
185¡ãF (85¡ãC) max

Braid resistance:
Tinned copper 0.003 /ft

Description
The 2800 family of self-regulating heaters is designed for all your commercial freeze protection applications. Self-Regulating design allows for safety and ease of cut-to-length installation, RSCC Dekoron self-regulating heating cables regulate heat output automatically in response to changes in temperature. The highly engineered, conductive core increases its heat output when the temperature falls and decreases its heat output when the temperature rises.
